Solução de resfriamento líquido em nível de ambiente

Capacidade de troca de calor: 1000kW, 1500kW, 2000kW

Visões gerais

A centralized liquid-liquid cooling unit for large data centers (100+ liquid cabinets), with 1000kW-2000kW capacity. Uses dual liquid circuits (deionized water/coolant) and N+1 redundant pumps. Enables online maintenance, remote monitoring, and fault early warning. Suits large-scale cold-plate server deployment, HPC clusters, and large AI model training centers requiring high reliability.

Pergunte agora

Características
Especificações
Aplicações
Download

Cenários de Aplicação

Medium-to-large liquid cooling data centers with large-scale deployment of cold plate liquid-cooled servers and high reliability requirements (suitable for 100+ liquid cooling racks or above).

High-Performance Computing (HPC) clusters, such as CPU/GPU-intensive scientific computing (e.g., weather simulation, gene sequencing).

Intelligent computing centers with large GPU clusters, used for AI large model training.

Product Features

High Cooling Capacity: Provides cooling capacity ranging from 1000kW to 2500kW.

High System Reliability: Adopts N+1 redundant pumps, multiple filters, and independent leak detection systems, ensuring continuous cooling during maintenance or faults.

Online Maintenance: Supports real-time online water quality monitoring and online coolant replacement, maintaining the system in optimal operating condition.

Remote Management: Integrates industrial communication protocols like Modbus and BACnet, enabling remote data monitoring and fault early warning to enhance management efficiency.

Ler mais
Modelo SY-CDU-RM-1000 SY-CDU-RM-1500 SY-CDU-RM-2000

Room - Level Liquid - Cooling CDU Heat Exchange Capacity 1000kW 1500kW 2000kW

Overall Parameters Overall Dimensions 1000mm×1500mm×2200mm 1396mm×2192mm×2245mm 1396mm×2192mm×2245mm

Net Product Weight ≤2000kg ≤3000kg ≤4000kg

Operating Weight ≤2150kg ≤3150kg ≤4150kg

Operating Noise ≤72dB

Potência nominal 38kW(Max) 40kW(Max) 55kW(Max)

Fonte de energia AC380V, 50Hz

Communication Protocol Modbus RTU

Secondary Side Parameters Circulation Medium Deionized water

Circulation Flow Rate ≥170m³/h ≥260m³/h ≥340m³/h

Number of Circulation Pumps 1 main

Supply Liquid Pressure ≥0.4MPa

Supply Liquid Temperature ≤40℃

Primary Side Parameters Circulation Medium Deionized water, coolant

Circulation Flow Rate ≥140m³/h ≥210m³/h ≥280m³/h

Return Liquid Temperature ≤43℃

Ler mais
Ler mais
Ler mais

Produtos relacionados

Etiquetas:

Anterior: Solução de resfriamento líquido-líquido em nível de rack

Contate-nos

Entre em contato para obter suporte técnico e de produtos

Alterar idioma

Solução de resfriamento líquido em nível de ambiente

Produtos relacionados

Solução de resfriamento líquido em nível de linha

Solução de resfriamento líquido-líquido em nível de rack
